The business includes aviation transmission products, high-speed gear transmission products, high-speed inertial flywheel, torque loader, aero-engine component test bench, and other fields of test bench development and sales, transmission equipment testing, fault diagnosis and maintenance services.
Product Model: HLP500B-30K
Transmitted Power: Prated=250kW，PMax=500kW
Rated Input Speed: 0~4000 rpm
Rated Output Speed 1: 0~18000 rpm
Rated Output Speed 2: 0~30000 rpm
Rotation Direction: Reversible
Vibration Limit Value (Velocity RMS): 4.5mm/s
Lubrication Flow Rate: 40L/min
Oil Supply Pressure: 0.2±0.05 MPa
Product Model: HLP500-30K
Transmitted Power: Prated=250kW，PMax=500kW
Rated Input Speed: 0~4000 rpm
Rated Output Speed 1: 0~18000 rpm
Rated Output Speed 2: 0~30000 rpm
Rotation Direction: Forward and Reverse
Vibration Limit Value (RMS Velocity): 4.5mm/s
Lubrication Flow Rate: 40L/min
Supply Oil Pressure: 0.2±0.05 MPa
Product Model: HL870-4000
Maximum Speed: 4000rpm
Maximum Torque: 4200Nm
Lubricant Grade: 10W Transmission Oil
Lubricating Oil Pressure: 0.25±0.05MPa
Oil Supply Temperature: 75±5℃
Product Model: HLP280-360
Power Transmission: 280kW
Rated Input Speed: 0~2880 rpm
Rated Output Speed 1: 0~18000 rpm
Rated Output Speed 2: 0~36000 rpm
Rotation Direction: Reversible
Vibration Limit Value (Velocity RMS): 4.5mm/s
Lubrication Flow Rate: 50L/min
Oil Supply Pressure: 0.2±0.05 MPa
Power Transmission: 370kW
Rated Input Speed: 0~5000 rpm
Rated Output Speed 1: 0~15000 rpm
Rated Output Speed 2: 0~35000 rpm
Rotation Direction: Forward and Reverse
Vibration Limit Value (Velocity RMS): 4.5mm/s
Lubrication Flow Rate: 38L/min
Supply Oil Pressure: 0.2±0.05 MPa
Why choose us
Assembly and test verification capability
It has a test assembly plant of 3000m ², equipped with high-precision lathes, grinders, milling machines and other equipment. Adhere to zero defects in products, attach importance to the construction of quality system, and build a high-speed transmission comprehensive test bench. The maximum test power of the test bench is 200kW, the maximum test speed is 60000r/min, and the maximum oil supply capacity is 200L/min. Equipped with DEWETRON vibration monitoring system, Easy-laser laser laser alignment instrument and Hikvision closed-circuit monitoring system, it can meet the comprehensive operation test of gear box, inertial flywheel unit, air compressor, clutch and other products, and can provide fault analysis service of rotating parts.
Complete system design and analysis capabilities
Our company has complete mechanical transmission design and analysis capabilities, including the following: • Overall mechanical system design and R & D capability • Rotor dynamics system analysis • Shell Finite Element Analysis • Coupling design and application technology • Lubrication system design and • Aerodynamic analysis • Gear transmission system design and analysis • Bearing analysis and application technology: sliding bearings/rolling bearings • Ability to design and analyze shaft parts • Connection design analysis: bolt/pin/spline/flat key/interference connection • Seal design and analysis • Vibration testing and analysis
Design fast response capability
It has complete staffing for mechanical transmission design and electrical drag measurement and control technology, covering all aspects of system overall design, zero/component structure design, system analysis and calculation, testing, assembly and testing verification, and can quickly grasp and understand customer needs. At the same time, combined with the company's experience in large-scale mechanical transmission projects, it can quickly provide customers with complete customized mechanical system solutions.
Excellent customer service experience
We continue to provide customers with systematic mechanical transmission solutions, such a business model requires the company and customers in-depth communication and coordination process, familiar with customer products, familiar with customer needs and expectations, from the customer's point of view, in order to maximize customer value as the core.
Technology and Services
Technology Center
Hunan Air Force Transmission Technology Center was established by the former AVIC Aviation R & D team, focusing on the field of mechanical transmission. The technology center covers six technical directions: overall system design, structural design of parts/components, system analysis and calculation, testing, assembly and test verification.
Testing and Services
In order to verify the design of new products and ensure the quality of product development, our company has invested in the construction of a high-speed transmission comprehensive test bench. The motor power of the test bench is 250kW (expandable to 500kW); Through the gearbox speed increase, the maximum test speed can reach 60000r/min; With torque loading capacity, the loader has a maximum working speed of 8000rpm and a maximum loading torque of 600Nm; Servo electric cylinder; Can supply oil to four equipment at the same time, with a single maximum oil supply capacity of 200L/min. The test bench is equipped with Austrian DEWETRON vibration test and analysis system, EasyLaser laser alignment, Hikvision closed-circuit monitoring system, analog real-time monitoring system for temperature, pressure, flow, etc., and belt drive dynamic balancing machine.
fault diagnosis of rotating machinery
Based on extensive experience in drivetrain design and analysis, testing and service, provide customers with services such as condition monitoring of machinery and equipment, fault diagnosis of rotating machinery, on-site dynamic balance, installation and disassembly guidance of mechanical transmission system, failure analysis and upgrading of mechanical transmission system, design and upgrading of transmission system, precision centering, upgrading of transmission system, spot inspection and maintenance packaging of equipment, design and implementation of online condition monitoring scheme, etc.
Regenerative Manufacturing Services
The high-speed gearbox of a certain type of test bench has the problems of large vibration, spline wear, bearing temperature rise and oil leakage. After several years of use, the vibration is seriously excessive and can no longer be tested. Customers seek solutions. After communicating with customers, the relevant technical personnel of our company will introduce the remanufacturing concept of transmission equipment to customers.
